AUDIO ADAPTERS
JACKS AND PLUGS
FAX: 773 792-2129
* Please visit the product pages on our website for the most up-to-date product information
159
AUDIO ADAPTERS
336A
340
345A
336B
349A
Part Number 332A (Not shown): 2-cond. phone jack input
to old MC1M-style microphone connector output. Coupling
ring can be screwed back to convert female microphone
connector to male type. Shielded.
Part Number 336A: 2-conductor phone jack input to a
phono plug output. Shielded.
Part Number 336B: 2-conductor phone jack input to phono
jack output. Shielded.
Part Number 340: Two 2-conductor phone jack inputs
connected in parallel to a 2-conductor phone plug output.
Shielded.
Part Number 345A: Phono plug input to a standard
2-conductor phone plug output. Shielded.
Part Number 349A: Phono plug coupler. Phono Extension
Jax ? input to phono Extension Jax output. Shielded.
? Part Number 352A: Stereo to monaural adapter.
3-conductor phone jack input to 2-conductor phone plug
output. Extra-wide insulator prevents accidental damage
should wrong connection be made. Shielded.
Part Number 361A: Phone plug coupler. Standard 1/4"
inside diameter phone jack input to standard 1/4" inside
diameter phone jack output. Ideal for connecting two
cables terminated with 2-conductor phone plugs. Shielded.
352A
361A
Part Number 362A (Not shown): Phone plug coupler.
Standard 3-cond. phone jack input to standard 3-cond.
phone jack output. Ideal for connecting two cables terminated
with 3-conductor phone jacks. Shielded.
Part Number 363: Phone jack coupler. Standard 1/4"
2-conductor phone plugs at each end to connect two
cables terminated with phone Extension Jax. Shielded.
Part Number 364A: EIA Standard 2-conductor Tini-Jax ?
363
365
374
364A
370A
376
phone jack input to a standard 1/4" 2-conductor phone
plug output. Shielded.
Part Number 365: EIA Standard 2-conductor Tini-Jax ?
phone jack input to a phono plug output. Shielded.
Part Number 370A: 2-conductor EIA Standard Tini-Plug ?
phone plug (.141" diameter finger) output to phono jack
input. Adapts standard phono plug to small Tini-Plug.
Shielded.
Part Number 374: 2-conductor phone jack input to a
2-conductor EIA Standard Tini-Plug (.141" diameter finger)
phone plug output. Adapts standard phone plug to small
Tini-Plug.
Part Number 376: EIA Standard Tini-Jax phone jack input
to a 2-conductor Micro-Plug (.097" diameter finger) phone
plug output. Adapts a Tini-Plug phone plug to a Micro-Plug
phone plug.
Part Number 377: Micro-Jax phone jack input to a
2-conductor EIA Standard Tini-Plug (.141" diameter
finger) phone plug output. Adapts a Micro-Plug phone plug
to a Tini-Plug phone plug.
? Special order only. Contact Switchcraft.
377
DIMENSIONS ARE FOR REFERENCE ONLY
SWITCHCRAFT, INC. 5555 N. Elston Ave. ? Chicago, IL 60630
Inch
(mm)
